VERO-S WDM-5X-BM Direct Clamping System

Product image 1
1 / 4

VERO-S WDM-5X-BM Direct Clamping System

#All
Product Details
  • Workpiece direct clamping system
  • Highly flexible
  • Basic module
#80125
Technical Data
  • Dimensions: 168 x 130 x 125 mm
  • Pull-down force: 25 kN
  • Actuation torque: 15 Nm
  • Repeat accuracy: < 0.005 mm
  • Weight: 6.65 kg
#80150
Technical Data
  • Dimensions: 168 x 130 x 150 mm
  • Pull-down force: 25 kN
  • Actuation torque: 15 Nm
  • Repeat accuracy: < 0.005 mm
  • Weight: 7.6 kg
Select Size
From $438.00

Original: $1,460.00

-70%
VERO-S WDM-5X-BM Direct Clamping System—

$1,460.00

$438.00

Product Information

Shipping & Returns

Description

#All
Product Details
  • Workpiece direct clamping system
  • Highly flexible
  • Basic module
#80125
Technical Data
  • Dimensions: 168 x 130 x 125 mm
  • Pull-down force: 25 kN
  • Actuation torque: 15 Nm
  • Repeat accuracy: < 0.005 mm
  • Weight: 6.65 kg
#80150
Technical Data
  • Dimensions: 168 x 130 x 150 mm
  • Pull-down force: 25 kN
  • Actuation torque: 15 Nm
  • Repeat accuracy: < 0.005 mm
  • Weight: 7.6 kg
